Characterization
NNF Staff Contacts : Nicole Hedges and Phil Barletta
![Pic36](https://nnf.ncsu.edu/wp-content/uploads/2023/06/Pic36-scaled.jpg)
Probe Station
Characterization Equipment
HP 4280A 1MHz C Meter/ C-V Plotter
HP 54520A 500MSa/s 500MHz Oscilloscope
HP 4156A Precision Semiconductor Parameter Analyzer
HP 6623A System DC Power Supply
Anechoic Chamber
This anechoic chamber provides a low reflection environment to measure antenna radiation pattern, gain, and reflection coefficient from 0.7 – 18 GHz. It can also serve a shielded room for wireless testing.
![](https://nnf.ncsu.edu/wp-content/uploads/2018/01/Antenna-Chamber.jpg)
